Duplex Filter Housing
$0.00
Inquiry Based
Features: • Aseptic style housing seal provides enhanced drainability and a crevice free connection between the housing head and bowl • Mirror-polished head, elbows, and bowl ensures optimal cleanability in critical areas • Operator friendly V-band clamp housing closure simplifies handling • Low pressure drop Applications: Power Plant, Process Industries, Cement Plant, Steel, Petrochemicals, Fertilizers, Refineries, Oils & Gas, Chemicals
| Parameter | Specification |
| Flow Rate | Up to 1000 m³/hr, more on request |
| Design Code | Good Engineering Practice, ASME section VIII Division 1 |
| MOC | MS, CS, Duplex 2205, Super Duplex 2507 |
| Pressure Rating | 1 - 15 bar |
| Temperature Rating | -25°C to +65°C, more on request |
| Connection Size | 4" - 20" |
| Connections | Flange |
| Vessel Closure | TC Clamped, Bolted |
| Sealing Material | Silicon / Neoprene / EPDM / NBR / PTFE / Teflon / Viton |
| Lifting Device | Davit Arm, Lifting Lug, Lifting Handle |
| Vessel Support | Legs, Skirt |
| Surface Finish | Matt Finish, Mirror Finish, Paint |
| Optional Finish | Rubber / FRP Lining and/or Painting |
| Customized Design | Available on request |
| Accessories (Optional) | Pressure Gauge, Vent Valve, Drain Valve, D.P. Gauge |
